MTZ 952.2 - Page 200

Maintenance
MTZ series 900
200
Action 35a. Checking the oil level in
the casings of the “wet”-type brakes
To check the oil level in the casings of
the “wet”-type brakes, proceed as fol-
lows:
 Place the tractor on a flat level area;
 Screw out the check/fill plugs (1) in the
right and left casings of the brakes;
 The oil level in the casings of the
brakes shall be to the edges of the holes
of the check/fill plugs (1) on the front
walls of the casings;
 If necessary, add oil through the holes
of the plugs (1);
 Screw in the plugs (1).
Action 36. Oil level in the FDA casings
I. FDA with bevel reducing gears
(920/952)
Check the oil level in the:
1 . wheel reducing gears (lower bevel
pairs);
2 . main gear (front differential) casing;
3 . cardan drive intermediate support;
4 . upper bevel pair casings.
The oil level shall be to the lower edges
of threaded check openings (1).
If necessary, add oil to the level through
the check openings.
