Grammer Seat
(if installed)
Important! Prior to beginning the op-
eration of the tractor, adjust the seat
to the position being the most conven-
ient for you. Perform all the adjust-
ments while sitting on the seat.
The seat is provided with mechanical
suspension having the total travel of 100
mm and hydraulic shock absorber pro-
tected by a rubber boot.
The armrests being adjustable to height
and safety belts are standard.
The seat is equipped with the following
controls (handles):
1. Back inclination: to 12.5° forward and
5° backward with the step of 2.5°.
2. Weight indicator.
3. Weight control: from 50 to 130 kg
steplessly.
4. Forward/backward motions: within
the range of 150 mm with the step of
15 mm.
The adjustment of the seat height within
60 mm is provided in three positions. To
set the required height, pull the seat
upwards. The indicator click determines
a new position. Should the seat be
pulled upwards from the uppermost po-
sition, the lowering mechanism will op-
erate and the seat will be lowered to the
lowermost position.
Note: Do not use solvents for clean-
ing the seat upholstery. Use only
warm water with small amount of de-
tergent.
