Г15 Lifting THM of the tractors equipped with hydraulic lift
1.ТСУ-2В (fork)
Machines: semi-trailed (semi-trailers, machines for fertilizing, etc.), trailed (disk harrows,
tillers, hoeing ploughs, hitch of harrows, cultivators and seeders, etc.).
Fork with the possibility of the verti-
cal displacement
Distance from the fork to supporting surface for
machines without PTO drive, mm
403.. .858 (91 8*) stepwise
via 65 mm
Fork position for machines with PTO drive
Distance from PTO face to attachment pin ax-
le, mm
Vertical load on THM, kN (kg f)
Machine turning angle relative to the tractor, de-
gree
* With turning over the fork
