KIROVETS K-744R1, K-744R2, K-744R3, K-744R4 tractors
190
APPENDIX 9B
List of electrical equipment elements to the electrical diagram
of the K-744R2, K-744R3, K-744R4 Standard tractors
Pos.
Designation
Description
Q-ty
Note
А1
Avgust air conditioner
1
А2
Air conditioner control panel
1
ВК
Sensor TM100 TU37.003.271-76
1
Temperature of
engine cooling
fluid
Pressure sensors TU37.003.387-78:
ВР1
18.3829010
1
Engine oil
ВР2
19.3829010
1
Gearbox oil
ВР3
Pressure sensor 3902.3829 GOST 1701-75
1
Air in PS
(pneumatic
system)
BV1
Speed sensor 11.3843-У-ХЛ TU37.003.1148-83
1
Speedometer
EK1, EK2
Plug 11.3740 TU37.003.741-80
2
Thermostart
Transport lamp 1АВ006213-001:
EL1,
1
EL2,
1
EL22,
1
EL23
1
Working lamp 781.3711 TU 4573-024-05808936-95:
EL3, EL4,
2
EL5, EL6,
2
EL7, EL8,
2
EL9, EL10
2
EL11
Under-boot lamp ПД308А-У-ХЛ TU37.003.187-80
1
EL12...EL18
Lamp А24-2 GOST 2023.1-88
7
EL20
Ceiling lamp 11.3714010 TU37.003.818-77
1
EL21
Licence plate illumination light ФП-131-Б GOST
6964-72
1
Fuses TU37.469.013-95:
FU1, FU2,
352.3722 (10А)
16
To be used with
the fuse block
41.3722
FU4,FU6,
FU7, FU10,
