GY
WH
OR
SYSTEM
FAULT
ALARM
OUTPUT
OPTIONAL
1 AMP
-0V
EARTH
IGNITION
OUTPUT
TO RUN
SOLENOID
5 AMPS
+7V - 35VDC
PROTECTED
SWITCH IGN +
SUPPLY
YL/BU
GN
BK
+
-
+
-
CYLINDER
DISCHARGE
PRESSURE
SWITCH
900KPa
CYLINDER
LOW
PRESSURE
SWITCH
1200KPa
P
STAGE 2
STAGE 1
CYLINDER PRESSURE LOW
PU
AUXILLIARY
OUTPUT
CONTROL
REFER TO
WIRING
INSTRUCTION
1 AMP
NO
RD
7V - 35V
BATTERY+
FROM
PROTECTED
SUPPLY
NOTE:
BOTH PRESSURE SWITCHES
DRAWN WITH THE FIRE
CYLINDER FULLY PRESSURISED
INPUT 1INPUT 2
1
2
3
4
5
6
7
8
P
NO
SYSTEM OVERRIDE
TEST SWITCH
1 SHOT O'RIDE
SHUTDOWN
BYPASS
POWER ON /
CYLINDER PRESSURE OK
SYSTEM FAULT /
CYLINDER PRESSURE LOW
SYSTEM DISCHARGE /
ENGINE SHUTDOWN
WARNING
WHEN FIRE UNIT IS ACTIVATED
SIREN WILL OPERATE AND ENGINE WILL
SHUT DOWN AFTER TIME DELAY
PANEL
TEST
FIRE STATUS PANEL
1 2 3 4 5 6 7 8 9 10 11 12
B
A
C
D
E
F
G
H
B
A
C
D
E
F
G
H
1 2
3
4
5 6
7
8 9 10
11 12
A4
COPYRIGHT - ALL RIGHTS RESERVED
This drawing is the property of REMOTE
CONTROL TECHNOLOGIES PTY LTD (RCT),
and is not to be copied or used in whole or in
part for any purpose without the express
authority of RCT. The drawing is to be returned
to RCT, on demand.
FIRE SYSTEM
STATUS PANEL
EXTERNAL WIRING
www.rct.net.au
UNCONTROLLED DOCUMENT
REV
5
DWG No
300o
STATUS
NTS
SCALE
Released
SHEET
1 of 1
BY
BT
DRN
RH
DATE
21/06/07
APPD
BT
DATE
----
STOCK
CODE
MH-FC-AS5062-P
PART
NO
5884
3rd ANGLE
PROJECTION
ALL DIMENSIONS IN MILLIMETERS
NOTE: FIRE PRESSURE SWITCHES ARE WIRED
TO BATTERY AND ARE WIRED IN A FAIL
SAFE MANNER. eg WHEN THEY BECOME
OPEN CIRCUIT THE INPUT IS ACTIVATED.
WIRE LEGEND
BK - BLACK PK - PINK
BU - BLUE PU - PURPLE
BN - BROWN RD - RED
GN - GREEN WH - WHITE
GY - GREY YL - YELLOW
OR - ORANGE
REV ZONE DESCRIPTION BY DATE
1
'IGNITION' CHANGED
TO 'BATTERY'
SF 10/11/08
2
ADDED PROTECTED
SWITCH IGN SUPPLY
SD 06/08/09
3
SWAPPED WIRES
COLOURS ON 4 AND 8
SD 06/04/11
4
update titleblock and label
GT 30/07/15
5 E6
connected pressure
switches to battery not
ignition
JB
20/08/15
To Next Page
