Listed below are part numbers
them to another
manufacturer’s
for the
4/8
pin
series T-connector.
part
number.
If
your telephone accessories
retailer
does
not
have
the part
numbers listed
in
his
catalogs,
ask him to
cross
reference
Part No.
AT 267 SB
304A
Manufacturer
Allen
Tel
AT&T
Functions/
Operations Check
After installing the ACP
on
the
phone line, it
is
wise to make a
“functions check” of the unit
and the phone system wiring.
To
check the phone system
wiring:
1.
Check
all
telephones for dial
tone. If
none
is
present,
unplug the 8-wire line
cord
(which connects the ACP to
the phone line) from the
RJ-
31X walljack.
If
dial tone
is
returned to the phones after
unplugging the line
cord,
check
the line
cord
connection at the
LINE/DEVICE
1”
port
of the
ACP
3/5.
Reconnect the line
cord
to the RJ-31X walljack.
Dial tone should be returned
to the phone system.
2. If dial tone
is
present but
you
can not dial out
on
the line,
the phone
line
polarity may
need to be reversed. This
can be done by switching
the “tip and ring” wires
on
the incoming line at the
RJ-
31 X walljack.
3. After connecting the
specified data equipment to
the
device
ports at the rear
of the ACP (DEVICE
2/DEVICE
3 for the ACP
3-DEVICE
2/DEVICE
3/DEVICE
4/DEVICE
5 for
the ACP
5),
the unit should
be tested for
call
routing
capability. This can be done
by contacting the central
office
or location that
will
be
polling
such
equipment and
give them the location phone
number and
device
selection
codes
(if known).
TO THE INSTALLER: If the
ACP 3 or 5 fails to
operate
at
any
time after installation
please
contact
the location
supervisor or corporate MIS
Manager.
9
