Multi 210 User Manual

Accuracy: AC 50/60Hz (23℃③5℃, less than 80% RH)
Range
Mini. Resolution
Accuracy
AC 20A
0.01A
③1.2%rdg ③5dgt
AC 200A
0.1A
Jaw opening capability
23mmφ
Over range indication
Blanking of all digits except MSD1
Maximum indication
1999 count
Low battery indication
"B" mark on LCD readout
Data hold indication
"D･H" mark on LCD readout
Sampling time
2 times/sec.
Limitation of circuit voltage
Less than AC 600V
Withstanding voltage
AC3700V/1 minute between CT core and outer case
Insulation resistance
10MΩ or more between internal circuit and CT core.
Operating temperature
0℃ to +40℃, ＜80%RH (non-condensing)
Storage temperature
-10℃ to +60℃, ＜70% RH (non-condensing)
Power supply
LR-44(1.5V)x2 or SR-44x2
Power consumption
Approx. 2.5mW
Battery life
Approx. 100 hours (LR-44)
Approx. 200 hours (SR-44)
Size
48(W)x146(H)x20(D)mm
Weight
Approx. 80g
Accessories
Batteries (LR-44)…….…….2
Instruction manual……..…1
Soft case……………….…….1
3. CAUTION
● Before operating this instrument, familiarize yourself with all instructions
outlined in this manual.
● Always check to make sure that the function switch is set to the proper position.
● When making measurements, use CAUTION as dangerous voltages may be
present in normally safe areas.
● To avoid electrical shock, use CAUTION when working above 60V DC or 25V AC
rms. Such voltages pose a shock hazard.
● Never make measurements with the battery cover OFF.
● Never fail to keep the maximum tolerable input.
● Never operate this instrument if it becomes wet, damp or has any liquid
condensation build-up on any part of the instrument.
● Never make measurements for uninsulated conductors or bus bars.
