Multi 3000 User Manual

Manual for MULTI Winch 3000 & 5000
TREJON AB - 12 - www.trejon.se
Instructions for Use and Maintenance WINCH 5000
Log-winch MULTI 5000 (hereinafter winch) is meant for hauling and gathering tree-trunks/logs
and further transporting them out of the forest.
Requirements to tractor:
Type Wheel-tractor
Category 2
Power, kW 30…75
PTO shaft 540 r/min
Winch has to be attached to the hanging mechanism of the tractor and be put into operation
through PTO shaft with 540 r/min.
TECHNICAL DATA
Pulling force 50 kN
Dimensions:
length, cm
width, cm
height, cm
60
150
170
Weight, kg 340
Number of hooking chain 5
Cable dimensions:
length, m
diameter, mm
reeling speed
50
10
0,6…1,3 m/sec
Personnel needed 1 operator
We reserve the right to change the construction and specification details without notice.

Multi 3000 Specifications

General

Type	Electric Winch
Voltage	12V
Rated Line Pull	3000 lbs
Battery Requirements	650 CCA
Cable Length	50 ft
