Multi 600 User Manual

3. SPECIFICATION
3-1. General Specification
Measuring sensor : Hall effect
Measuring function : DC current, AC current (true rms reading) with automatic zero
adjustment, max, hold, min, hold, data hold, auto power off
Display : 3.5 digit LCD, max. reading of 1999
Range : AC/DC 200mA, 2000mA, 10A
Sampling time : 1.6 times/sec.
Over range indication : “OL” mark on LCD readout
Data hold indication : "D･H" mark on LCD readout
Low battery indication : "B" mark on LCD readout
Limitation of circuit voltage : Less than AC/DC 300V
Withstanding voltage : AC 2300V/1 minute max. between the core of CT and outer
case.
Operating temperature : 0℃ ~ 50℃, ＜80%RH (non-condensing)
Storage temperature : -20℃ ~ 60℃, ＜75% RH (non-condensing)
Power supply : 1.5V (“AA” size, UM-3) x 2
Battery life : 120 hours or more (Alkaline)
Auto power off : The meter is set to power off mode approx. 10 minutes after the
power switch on.
Size : 76(W)x194(H)x30(D)mm
Weight : Approx. 340g
Accessories : Carrying case:……………..1
Instruction manual………1
Batteries……….…………..2
3-2. Measuring Range
Note : Electrical characteristic (18℃ ~ 28℃, 80%RH max.)
Range Input Resolution
A
ccuracy
ACA
200mA 0~199.9mA
100μA ±1.0%rdg±5dgt (50/60Hz)
2000mA 0~1999mA 1mA
±1.0%rdg±5dgt (50/60Hz)
10A 0~9.99A 0.01A
±1.0%rdg±10dgt (50/60Hz)
DCA
200mA
0~±199.9mA 100μA ±1.0%rdg±3dgt±(3%rdg‡)
2000mA
0~±1999mA
1mA
±1.0%rdg±3dgt±(3%rdg‡)
10A
0~±9.99A
0.01A
±1.0%rdg±10dgt±(3%rdg‡)
‡: Error by hysteresis of hall effect.
