Multihog CX75 - Secure Trunk to Cab

FIG. 7
Attach the Trunk to the Cab using the bolts, spacers and washers supplied as above. Bolt the
trunk frame mounting points highlighted in red above in Fig. 7 to the tapped bushings on
the cab highlighted in blue.
5MM WASHER
BUSHING TOP
BUSHING
BOTTOM
12MM SPACER
4MM S.S
WASHER
M16 X 120 BOLT, FLAT & SPRING WASHER
40mm x 20mm
Bushing
