Chapter 1: Product Description and Specifications
Multi-Tech Systems, Inc. FaxFinder Admin User Guide 7
Technical Specifications
FF130/230 FF430/830
Connectors RJ11 Line Jacks (1 or 2), Console Serial Port
for configuration / debug, Ethernet RJ48,
and Locking Screw on the Power Jack.
RJ11-Line Jacks (4 or 8), Command Serial
Port for configuration / debug, Ethernet
RJ45
Size
6.4” W x 6.0” L x 1.2” H (16.3 cm x 15.2 cm x 3.0 cm) 17.3” W x 1.7” H x 8.4” L (43.9 cm x 4.3 cm x 21.3 cm)
Weight 1.22 lbs. (0.55 kg) 1.25 lbs (0.57 kg)
6.86 lbs (3.11 kg) 7.15 lbs (3.24 kg)
Input Power
Requirements
9 Vdc @ 590mA
100 – 240 Vac, 50/60 Hz, 1.2 – 0.6 A
Maximum Power
Consumption*
FF130
9 Vdc, 0.53 Amps, 4.73
Watts
20 Vdc, 0.23 Amps,
4.54 Watts
32 Vdc, 0.16 Amps,
4.96 Watts
FF230
9 Vdc, 0.58 Amps, 5.22
Watts
20 Vdc, 0.25 Amps,
5.04 Watts
32 Vdc, 0.17 Amps,
5.41 Watts
FF430
120 Vac/60Hz, 0.16A,
18.33 W
220 Vac/50Hz; 0.12A,
28.07 W
FF830
120Vac/60Hz, 0.19A,
22.80 W
220Vac/50Hz; 0.14A,
32.25 W
Operating
Environment
32°-104° F (0°-40° C)
relative humidity 20 to 90% noncondensing
32°-140° F (0°-60° C)
relative humidity 20 to 90% noncondensing
Storage Temp.
14° to 185° F (-10° to +85° C) 14° to 185° F (-10° to +85° C)
EMC Approvals FCC Part 15 Class A, EN 55022, EN 55024
FCC Part 15 Class A, EN 55022, EN 55024
Safety Approvals
UL\cUL 60950-1, EN 60950-1 UL\cUL 60950-1, EN 60950-1
Telecom
Approvals
47CFR Part 68, CS03, TBR21
Other countries also included
47CFR Part 68, CS03, TBR21
Other countries also included
Data Modem
Specs
ITU-T V.92/V.90/56K (-92 build),
V.34/33.6K V.32bis/14.4K
V.22bis/2400 baud
V.22, V.23, & V.21;
Bell 212A & Bell 103
V.44 Error Correction
V.42 LAPM, MNP 2-4 Error Correction
V.42bis & MNP Class 5 data compression
ITU-T V.92/V.90/56K (-92 build),
V.34/33.6K V.32bis/14.4K V.22bis/2400
baud
V.22, V.23, & V.21;
Bell 212A & Bell 103
V.44 Error Correction
V.42 LAPM, MNP 2-4 Error Correction
V.42bis & MNP Class 5 data compression
Fax Modem Specs ITU-T V.34 (MT5634SMI)
ITU-T V.17, V.29, V.27 & V.21 Ch. 2
Telephony/TAM
V.253 commands
2-bit & 4-bit ADPCM, 8-bit linear PCM & 4-
bit IMA coding; 8kHz sample rate
Concurrent DTMF, ring, & U.S. Caller ID
detection
ITU-T V.34 (MT5634SMI)
ITU-T V.17, V.29, V.27 & V.21 Ch. 2
Telephony/TAM
V.253 commands
2-bit & 4-bit ADPCM, 8-bit linear PCM & 4-
bit IMA coding; 8kHz sample rate
Concurrent DTMF, ring, & U.S. Caller ID
detection
Simultaneous
Scheduling
1 (Maximum) for FF130
2 (Maximum) for FF230
8 (Maximum)
Web Connections
10 (Maximum) 50 (Maximum)
File Upload Size
2 MiB (Maximum) 5 MiB (Maximum)
Warranty
2 years. 2 years.
* Multi-Tech Systems, Inc. recommends that the customer incorporate a 10% buffer into their power source when
determining product load.
