How to Order
To order your VS2 Series model use the diagram below.
Part number example: VS2EXR-24
___ – ___
Options
24 = 24 VDC reset coil on VS2EXR or VS2EXRB
15 = 115 VAC reset coil on VS2EXR or VS2EXRB
D = DPDT switch on VS2EXRB only
LC = Less case
LCC = Less cable and clamps on VS2C
Base Model
VS2
VS2C
VS2EX
VS2EXR
VS2EXRB
NOTE: Order C-clamp
mounting kit as a separate
line item for VS2EX and
VS2EXR.
Service Parts
When ordering service parts, specify both part number and descrip-
tion in listing below.
PART NO. DESCRIPTION
VS2 and VS2C
20-00-0030 Movement assembly
20-00-0031 Glass and gasket assembly
20-00-0032 Reset push button assembly
20-05-0021 Mounting clamp (VS2C)
20-00-0261 Cable clamp assembly (1 each) (VS2C)
20-05-0465 2-Conductor electrical cable, 45 feet (13.7 meters) (VS2C)
20-00-0137 5 clamps and 45 feet (13.7 meters) of cable (VS2C)
VS2EX
20-01-0091 Movement assembly
20-05-0087 Cover
00-00-0309 Cover gasket
20-01-0090 Snap-switch and insulator kit (1 switch per kit)
prior to September 1, 1995.*
20-00-0288 Snap-switch and insulator kit (1 switch per kit) for models
manufactured on September 1, 1995 or later.*
20-00-0289 C-clamp conversion mounting kit
VS2EXR
20-00-0262 Movement assembly
20-05-0087 Cover
00-00-0309 Cover gasket
20-01-0090 Snap-switch and insulator kit (1 switch per kit)
prior to September 1, 1995.*
20-00-0288 Snap-switch and insulator kit (1 switch per kit) for models
manufactured on September 1, 1995 or later.*
20-00-0049 Reset solenoid assembly (115 VAC)
20-00-0234 Reset solenoid assembly (24 VDC)
20-00-0289 C-clamp conversion mounting kit
VS2EXRB
20-01-0090 Snap-switch and insulator kit (1 switch per kit)
prior to September 1, 1995.*
20-00-0288 Snap-switch and insulator kit (1 switch per kit) for models
manufactured on September 1, 1995 or later.*
20-00-0057 Inside snap-switch and insulator kit (1 switch per kit) for
model VS2EXRB-D prior to September 1, 1995.*
20-00-0058 Outside snap-switch and insulator kit (1 switch per kit) for
model VS2EXRB-D prior to September 1, 1995.*
20-00-0287 Outside snap-switch and insulator kit (1 switch per kit) for model
VS2EXRB-D manufactured on September 1, 1995 or later.*
20-00-0290 Inside snap-switch and insulator kit (1 switch per kit) for model
VS2EXRB-D manufactured on September 1, 1995 or later.*
20-05-0077 Adjustment shaft
20-00-0262 Movement assembly
20-00-0049 Reset solenoid assembly (115 VAC)
20-00-0234 Reset solenoid assembly (24 VDC)
* Models with date 0895 and before use old switch. Dated 0995 after, use straight snap-switch
arm, no rollers.
Shipping Information
VS2 and VS2C
Shipping Weight:
VS2: 2 lb 8 oz. (1.1 kg)
VS2C: 7 lb (3.2 kg)
Shipping Dimensions:
VS2: 8-1/4 x 9-1/4 x 5 in. (210 x 235 x 127 mm)
VS2C: 12 x 7 x 5-1/2 in. (305 x 178 x 140 mm)
VS2EX
Shipping Weight: 4 lb 8 oz. (2 kg)
Shipping Dimensions: 8-1/4 x 9-1/4 x 5 in. (210 x 235 x 127 mm)
VS2EXR
Shipping Weight: 5 lb 8 oz. (2.2 kg)
Shipping Dimensions: 8-1/4 x 9-1/4 x 5 in. (210 x 235 x 127 mm)
VS2EXRB
Shipping Weight: 17 lb 8 oz. (7.9 kg)
Shipping Dimensions: 12 x 12 x 10 in. (305 x 305 x 254 mm)
