Murray 461004x92A - Page 44

REPAIR PARTSMODEL 461004x92A
44
F–040741L
SECTOR GEAR
1
2
3
4
5
6
7
8
9
10
11
7
6
12
13
Key
No. Part No. Description
1 009x62 Bolt, Shoulder
2 15x111 Nut, Lock
3 015x79 Nut, Flange
4 094384 Guide, Screw
5 690146E700 Link, Left Drag
6 17x168 Washer
7 015x84 Nut, Flange
8 690145E700 Link, Right Drag
9 001x84 Bolt
10 690180 Bearing, Sector Gear
11 092530 Fitting, Lub
12 690147 Gear, Sector
13 1001121E700 Plate, Steering
