Murray F4315120-DECK - Illustrated Parts Lookup - PRE-PAINT DECK ASSEMBLY; Deck Kit and Guards; Brackets and Lift Components; Quill and Spindle Assembly

Illustrated Parts Lookup
Parts for MURRAY Model "F4315-120", Image Section "015 - PRE-PAINT DECK ASSEMBLY"
Item Part Number Part Description Series QtyAlt Part
1 325116 43" DECK KIT
2 326480-853 QX TOE GUARD - MULCH
326480E701
3 180077 SCREW, 5/16-18X .75
4 1498 NUT, 5/16-18 REGHEXC
5 180077 SCREW, 5/16-18X .75
6 1498 NUT, 5/16-18 REGHEXC
7 317017 PF BRACKET CHUTE MOU
8 180077 SCREW, 5/16-18X .75
9 120393 WASHER, FLAT .344X
10 1498 NUT, 5/16-18 REGHEXC
11 313929 PF LIFT BRKT, REAR R
12 180077 SCREW, 5/16-18X .75
13 120393 WASHER, FLAT .344X
14 1498 NUT, 5/16-18 REGHEXC
15 310667 PF BRACKET,DECK LIFT
16 180077 SCREW, 5/16-18X .75
17 120393 WASHER, FLAT .344X
18 1498 NUT, 5/16-18 REGHEXC
19 326893-853 QX BRACE IDLER SUPPO
326893E701
20 180077 SCREW, 5/16-18X .75
22 44108 QX NUT, 5/16-18 WDFL
015X88
23 56424-853 R/B 327519, QUILL A
779066
23-1 56425 WS SHAFT/SADDLE 36"
23-2 49562 BRNG, BALL 6203-2AA-
23-3 50616 MS DUST SHIELD
23-4 55547 QUILL CASTING (1046)
23-5 49562 BRNG, BALL 6203-2AA-
23-6 50818 SPACER- QUILL
23-7 51449 SPACER, SLEEVE .672
23-8 313898 QX R/B 331188 PULLEY
331188
23-9 56365 WASHER, SPECIAL QUIL
23-10 1282 NUT, 7/16-20 WDFLLK
34 35498 R/B 782967, SCREW 5/
782967
35 300345 SCREW, 5/16-18X1.38
36 1498 NUT, 5/16-18 REGHEXC
37 317040 PF BRACKET FRT.
38 180077 SCREW, 5/16-18X .75
39 1498 NUT, 5/16-18 REGHEXC
40 58305-853 QXR/B 314070, BRACKE
314070
41 58247 NUT, ADJUST EOQ 500
42 180079 QX SCREW, 5/16-18X1.
001X84
43 1498 NUT, 5/16-18 REGHEXC
44 317041 PF BRKT, GAGE WHEEL
45 180077 SCREW, 5/16-18X .75
46 1498 NUT, 5/16-18 REGHEXC
47 322464-853 QX Bracket, Gage Whe
322464E701
48 314282-853 QX Bracket, Stablilz
314282E701
9/10/2004
Parts List Page 1
