Murray F4315120-DECK - Wheel and Washer Components; Brake System Components

Illustrated Parts Lookup
Parts for MURRAY Model "F4315-120", Image Section "015 - PRE-PAINT DECK ASSEMBLY"
Item Part Number Part Description Series QtyAlt Part
49 180077 SCREW, 5/16-18X .75
50 1498 NUT, 5/16-18 REGHEXC
51 317041 PF BRKT, GAGE WHEEL
52 2483 R/B 782214, WASHER
782214
53 47665 SCREW, 3/8-24X1.25NY
54 320576-853 IDLER ARM ASSEMBLY
54-1 322116-853 QX MP/MM ARM IDLER 4
322116E701
54-2 41601 RIVET, OVSET .187DIA
54-3 306973 BRAKE PAD - HARD-NF3
58 304420 BOLT, .500X2.15 HHS
59 996416 R/B 583409, WASHER,
583409
60 996307 WASHER, FLAT .391X1
61 45171 QX NUT, 3/8-16 HWDFL
015X68
62 326249-853 QX BRACKET, EXTENSIO
326249E701
63 180077 SCREW, 5/16-18X .75
64 180083 SCREW, 5/16-18X1.50
65 446363 WASHER, FLAT .375X
66 271184 NUT, 5/16-18 HEXKEPS
67 1498 NUT, 5/16-18 REGHEXC
68 321828 SF BLADE BRAKE ASSY.
68-1 135624 QX RIVET, TRSET .185
68-2 304119-853 QX HS BRAKE ARM
304119E701
68-3 306973 BRAKE PAD - HARD-NF3
72 180077 SCREW, 5/16-18X .75
73 120393 WASHER, FLAT .344X
74 1498 NUT, 5/16-18 REGHEXC
75 314079 ROD, BRAKE
314079E701
76 1502 QX NUT, 1/4-20 REGHE
782585
78 180079 QX SCREW, 5/16-18X1.
001X84
79 120393 WASHER, FLAT .344X
80 1498 NUT, 5/16-18 REGHEXC
81 325965 BELT GUIDE,43"DECK U
82 308231 SCREW, 1/4-20X1.25 H
83 311104 SCREW, 5/16-18X5.00
84 271184 NUT, 5/16-18 HEXKEPS
85 35410 R/B 782232 SPRING
782223
9/10/2004
Parts List Page 2
