Lubrication
Where To Lubricate (Gear Drive Models - Figure 16, Hydro-
Drive Models - Figure 17)
Models with grease fittings: Lubricate with
grease gun.
Apply grease with a brush to the areas shown.
Lubricate the areas shown with engine oil.
NOTE: Apply grease to the steering gear as sembly.
CAUTION: If the unit is operated in dry areas that have
sand, use a dry graphite spray to lubricate the unit.
Check The Tires
Check the air pressure in the tires. Tires with too much air
pressure will cause the unit to ride rough. Also, the wrong
air pressure will keep the mower housing from cutting level.
The correct air pressure is: Front Tires 0,97 BAR (14 PSI),
Rear Tires 0,69 BAR (10 PSI).
Disassembly
How To Replace The Mower Drive Belt (Figure 12)
1. Remove the mower housing. See the instruc tions on
“How To Remove The Mower Hous ing”.
2. Pull the belt retainer (A) away from the idler pulley (B)
and remove the mower drive belt (C).
3. Pull the belt retainer (D) away from the right mandrel
pulley (E) and remove the mower drive belt (C).
4. Pull the belt retainer (D) away from the left mandrel
pulley (F) and remove the mower drive belt (C).
5. To install the mower drive belt, reverse the above steps.
How To Remove The Mower Housing (Figure 20)
1. Move the blade rotation control (A) to the DISENGAGE
position.
2. If equipped, remove the gauge wheels.
3. Move the lift lever (B) to the level adjust ment position.
CAUTION: The lift lever is spring loaded. Make sure the lift
lever is locked in the LEVEL ADJUSTMENT position.
4. Remove the hair pins and the washers from the
adjuster arms (C). See illustrations “3” and “4”.
5. Remove the hair pins and washers from the suspension
links (D). See illustrations “1” and “2”.
6. Disconnect the extension spring (E) from the blade
control rod (F). See illustration “5”.
7. Disconnect the front hanger (I) from the axle support.
See illustration “6”.
8. Remove the mower drive belt (G) from the stack
pulley (H).
9. Pull the mower housing away from the right side of the
unit.
10. To install the mower housing, reverse the above steps.
How To Replace The Fuse
If the fuse is blown, the engine will not start. Remove the
fuse and replace with a 15 amp. automotive fuse.
Maintenance - Engine
We recommend that you see any Briggs & Stratton
Authorized Dealer for all maintenance and service of the
engine and engine parts.
NOTE: All the components used to build this engine must
remain in place for proper operation.
Emissions Control
Maintenance, replacement, or repair of the emissions control
devices and systems may be performed by any non-road
engine repair establishment or individual.
However, to obtain “no charge” emissions control service,
the work must be performed by a factory authorized dealer.
See the Emissions Warranty.
