ASSEMBLY
10
F–040715L
ASSEMBLY
Read and follow the assembly and adjustment instructions for your
mower. All fasteners are in the parts bag. Do not discard any parts
or material until the unit is assembled.
NOTE: In this instruction book, left and right describe the loca-
tion of a part with the operator on the seat.
WARNING: Before doing any assembly or mainte-
nance to the mower, remove the wire from the spark
plug.
PARTS BAG – CONTENTS
The fasteners and other loose parts are shown below. The fasteners are shown full size. The quantity is shown in brackets ( ).
2x82
(2) Carriage Bolt
14x79
(2) Wing Nut
17x47
(2) Washer
1001054
(2) Knob
25x3
(1) Bolt
17x146
(1) Washer
