1. Specifications
Horizontal design, R410A, Heating & Cooling
Model MUSTANG 24 MUSTANG 30
* Heating Capacity at Air 28℃, Water 28℃,Humidity 80%
Max Heating Capacity kW 24 30
Rated Heating Capacity kW 21.5 25.5
Input Power (Heating) kW 3.31 4.47
MAX C.O.P 6.5 6.7
C.O.P 5.7 5.7
* General data
Compressor type Scroll / R410A Scroll / R410A
Voltage 380-415V~50Hz/3PH 380-415V~50Hz/3PH
Running Current Heating A 6.7 8
Advised pool volume
(with pool cover)
m³ 75-120 90-130
Advised water flux m
3
/h 6.2~12 7.1~14
Water Pressure Drop KPa 16 18
Heat exchanger Titanium in PVC
Water connection mm 50
No. of Fan 1
Ventilation type Horizontal
Fan Speed RPM 650
Noise level(10m) dB(A) 47 48
Noise level(1m) dB(A) 57 58
Net Weight kg 91 113
Net Dimension (WxDxH) mm 1072*420*830 1072*420*830
Packing Dimension (WxDxH) mm 1155*471*885 1155*471*885
* Above data are subjects to modification without notice.
