Mutable Instruments Ripples User Manual

Front panel
Controls
A. Resonance. Ripples can
be set to self-oscillate with
a high resonance setting.
B. Frequency. The Cutoff
frequency of the filter.
C. FM Attenuverter. Adjusts
the amount and polarity of
frequency modulation from
the FM input.
Inputs and Outputs
1. CV inputs for Resonance,
Frequency (with 1V/Oct
scale) and FM.
2. Audio input.
3. Voltage-controlled out-
put gain for the LP4>VCA
output.
4. Filter outputs. 2-pole
band-pass, 2-pole low-pass,
4-pole low-pass, and 4-pole
low-pass with amplitude
controlled by input 3.
A
B
C
1
2
3
4
