4096-702
PRODELIN CORPORATION Small Aperture Universal Mount
_____________________________________________________________________________
5
Vertical – 18” – Pattern “A”
Vertical – 24” – Pattern “C”
Configuration 1
Ground Mount – Pattern “A”
Configuration 1
65°-85° - 16” – Pattern “A”
55°-75° - 16” – Pattern “B”
70°-85° - 24” – Pattern “C”
60°-75° - 24” – Pattern “D”
Confi
g
uration 1
5°-30° - 16” – Pattern “A”
5°-30° - 24” – Pattern “C”
Configuration 1
50°-70° - 16” – Pattern “A”
30°-70° - 16” – Pattern “B”
45°-70° - 24” – Pattern “C”
40°-65° - 24” – Pattern “D”
Configuration 2
5°-35° - 16” – Pattern “A”
5°-30° - 16” – Pattern “B”
5°-40° - 24” – Pattern “C”
Configuration 2
Figure 1
