Spare parts list
Nr. Description Nr. Description
0101 Crankcase 1102 Drive washer key
0102 Crankcase screws-set
0104 Spacer sleeve 1104 Propeller washer
0202 Front bearing 1105 Propeller screw
0203 Rear bearing 1107 Propeller screws - set
0204 Packing
0205 Rear cover bearing 0307 Carb. flange gasket
0304 Pressure nipple 0308 Carb. flange screws - set
0305 Pressure nipple gasket 1301 Reed valve case
0401 Cylinder 1302 Reed valve
0402 Cylinder screws - set 1303 Reed valve screws
0403 Cylinder nut 1304 Reed valve gasket-upper
0404 Cylinder gasket 1305 Reed valve gasket-bottom
0405 Exhaust screws - set 1306 Reed valve strap
0406 Exhaust nut 1307 Carburetor screws
0407 Exhaust flange gasket
0701 Piston
1300
(set)
= 1301 + 1302 + 1303 + 1305 +
1306
0702 Piston ring 3314B Electronic ignition 175 NP
0801 Piston pin 3314T Electronic ignition 175 NP TS
0802 Piston pin retainer 3309 Spark plug
1001 Crankshaft 1405 Ignition sensor fixing screws
1101 Drive washer 3229 Carburetor
