mxr Dyna Comp Deluxe - External Controls; Control Descriptions

M228 | Dyna Comp
®
Deluxe Compressor 2
1 CLEAN knob adjusts wet/dry signal mix added to the compressor’s ouput
2 OUTPUT knob adjusts volume of compressed signal
3 ATTACK switch toggles between slow & fast attack times
4 TONE knob shapes EQ of compressed signal
5 SENSITIVITY knob adjusts sustain time
6 FOOTSWITCH toggles effect on/bypass (blue LED indicates on)
External Controls
2
1
4
6
5
3
