my-PV AC-THOR User Manual

AC•THOR
®
/ AC•THOR
®
9s Operating instructions, version a0020806 32
The AC•THOR start page in the web browser gives the same information as the home screen on the
display. Navigation using the symbols bar is carried out in the same way. Further information in the
chapter "Control and display elements".
With device state "Off", the load control can be switched off.
A quick selection in the upper right corner allows direct access to the Web-Interface from other my-
PV devices in the network. The button "Search Devices" scans the network for my-PV devices.
TIP: If the device search does not produce a result, the IP address can also be
entered manually in the address line of the web browser.
URL: … / my-PV Websetup 00XXX.XX.html?ip= XXX . XXX . XXX . XXX
Consider that the appearance and the scope of options can change with updated software versions.
The AC•THOR data logger In the web browser gives the same information as the data logger on the

my-PV AC-THOR Specifications

General

Power Range	0-3 kW
Input Voltage	230 V
Frequency	50/60 Hz
Category	Controller
Operating Temperature	-25°C to +60°C
Communication	Ethernet, Modbus
Phases	1-phase
Output Power	0-3 kW
Type	AC-THOR
