my-PV AC-THOR User Manual

AC•THOR
®
/ AC•THOR
®
9s Operating instructions, version a0020806 7
We ask for your understanding that we cannot do any binding support for third-party
products. For questions about third-party products, please contact the technical support of the
respective company.
Not every signal source is approved for hybrid systems with battery storage. If necessary,
please contact the technical support of my-PV.
Operation with battery may require additional control parameters. In this case, please contact
the technical support of my-PV.
A number is assigned to the sensor in the order in which it is selected. The selection can be
deselected by tapping on the key once more.
To assign a sensor to the respective entry in the list, the serial numbers can be identified on a label
attached to the sensor wire.
TIP: As the measuring value of the sensor is already shown in the selection
list, an assignment can alternatively also be made by simply altering the
temperature on the sensor.
TIP: The use of a sensor is not necessary if the optional boost backup or
the legionella programme are not used and the heat generator is switched
off by a thermostat!
By saving the settings the commissioning for the use of excess power is finished.
Additional functions, such as the optional boost backup, must be set separately.

my-PV AC-THOR Specifications

General

Power Range	0-3 kW
Input Voltage	230 V
Frequency	50/60 Hz
Category	Controller
Operating Temperature	-25°C to +60°C
Communication	Ethernet, Modbus
Phases	1-phase
Output Power	0-3 kW
Type	AC-THOR
