TECHNICAL SUPPORT SERVICE MANUAL iCOOK | iBAKE | COOK | BAKE | SNACK | BAKERSHOP - DT.MS.CB.2202.2
4
1. DISASSEMBLY FOR SERVICE ACCESS
Warning: Before proceeding to disassemble any component, make sure
that the equipment is disconnected from the power supply.
1.1. Removing the door
Before removing the door, disconnect the communications cable attached to the oven
control. See chapter 5.5.
1.1.1. Side-opening ovens
The following picture shows how to remove the door on side-opening models. Remove the
3 screws in the picture and pull the door upwards.
Removing the door (side-opening models)
