2203M4-JE-MY-iS2-N_2017.04.
Chapter 2 Compressor Specifications and Configuration
Screw Compressor i-series 2.4
Configuration of Compressor
2-25
Figure 2-21
Exploded View of i160S/L Parts with Motor Spacer
