MYERS Illuminator E Series - Before Installing the Unit

114061H System Installation Manual
5
C H A P T E R 3
BEFORE INSTALLING THE UNIT
Installation Dimensions and Clearances
Figure 3.1 System Dimensions
Table 3.1 Dimensions
Unit (A) (B) (C) (D) (E) (F) (G) (H) (J) (K) (L) (M) (N) (P) (R)
Unit #1
47”
(119.60
cm)
30”
(76.34
cm)
25”
(63.62
cm)
22 1/8”
(56.30
cm)
8”
(20.36
cm)
11 ½”
(29.27
cm)
7”
(17.82
cm)
11 ½”
(29.27
cm)
4 3/8”
(11.14
cm)
3 3/8”
(8.59
cm)
9 ¼”
(23.54
cm)
21 ½”
(54.71
cm)
18 7/8”
(47.94
cm)
19 ½”
(49.53
cm)
2”
(5.08
cm)
Unit #2
76”
(193.39
cm)
48”
(122.14
cm)
25”
(63.62
cm)
19 ¾””
(50.26
cm)
18 7/8”
(47.94
cm)
47”
(119.60
cm)
49 5/8”
(126.05
cm)
2”
(5.08
cm)
Table 3.2 Required Clearances
Sides Top Front
0”
(0.0 cm)
12”
(30.5 cm)
39”
(100.0 cm)
Table 3.3 Conduit Knockouts
Larger Smaller
1 ¾” / 2”
(4.45 cm / 5.08 cm)
7/8” / 1 1/8”
(1.59 cm / 2.86 cm)
1
2
