AAT it is recommended to avoid using antennas made with ferromagnetic materials. Wherever
possible, use non-magnetic stainless steel bolts, aluminum and other non-magnetic materials.
There is 3 pin connector beside the tilt servo (in the purple circle). The diagram below shows the
wiring.
12V~16V power supply (shared AAT power supply voltage)
3. There are 2 aviation type connectors on the front panel. See the diagram below for wiring:
