MYPIN LC Series User Manual

SET
A/D convert data when no weight
on the loadcell,that is the factory
setting for zero point.
↓
SET
Zero point adjustment for current/volt output,4mA/
0.1V adjustable. Available when have analog
output.Factory setting,do not make modification.
↓
×××.×
×××.×
↓
×××.×
↓
If SEL=XXX1XX,
that means the user can’t do on-site weight adjustment by pressing UP/DOWN key.
If SEL=XXX0XX,
that means the user can do on-site weight adjustment by pressing UP/DOWN key.
Note:
*** X means the original data. Do not make modification.
***Just make modification to data 1/0
***Factory setting is XXX0XX. After on-site adjustment,make sure SEL=XXX1XX.This is to avoide incorrect display by user’s inapropriate key-pressing operation.
↓
SET
SET
Adjustment for large-tonnage scale loadcell:
A. Set USP=the total weight of all input loadcells(eg. each loacell is 1000KG, 3 loadcells in total, the total
weight is 3000kg.Then set USP=3000.).
Set PVF=0.000,
B. Record the displaying value(PV1) when no weight on the loadcells(eg.100.5kg).
C. Add the standard weight(the weight should be larger than 20% of the total loadcell weight,eg.500kg).
Recorder the displaying value(PV2)(eg. 630kg).
D. Calculation: The actual weight added(eg. 500kg)/(PV2-PV1)
eg.500/(630-100.5)=0.9442.
E. Calculation: USP*(The actual weight added/(PV2-PV1)).
eg. USP*(500/529.5)=2832.86,
Then set USP=2832.86 again.
F. The adjsutment is finished.
On displaying estate,press UP and DOWN key for more than 3 seconds to access to parameter SEL setting.The operation steps are
the same as the other settings. After setting, press UP and DOWN key to quit.
This operation is to modify SEL value ONLY.Other parameters are fixed by manufactor.Please do not make any changement.
Full point adjustment for current/volt output,20mA/
10V adjustable. Available when have analog
output.Factory setting,do not make modification.
A/D convert data when some
weights on the loadcell,that is the
factory setting for full point.
Note: All the above parameters are for factory setting.Do not make any adjustmnet.
