Technical specifications
AC ELWA
Voltage
200 - 250 V
Max. heatingpower
3000 W at 230 VAC
Mains connection
Single phase, grounded plug,
230 V, 50 – 60 Hz
safeguarding
13 A or 16 A
Connecting wire
2.8 m
Standby-
<1 W
Operating Pressure
max. 10 bar (1 MPa)
efficiency
>99 % at rated power
Protection
IP21
Operating temperature
range
10 ° C to 40 ° C
Operating status display
3 LED’s
Interface
1- wire- connection, max. AWG
16/1,5 mm²
Dimension (BxHxT)
130 x 180 x 600 mm incl. heating
rod
Heater length
47 cm
Immersions heater
connection
1 ½ Inch
Weight
2 kg incl. cable, without package
PLA
Voltage
1x230 V or 3x230 V
Consumption
<1 W
Cable cross section
max. 16 mm²
Max. current
63 A
Dimension (BxHxT)
71 x 90 x 58 mm
Weight
2000 g
Water protection
IP20
Operating temperature
range
10 ° C to 40 ° C
Operating status display
3 LED’s
Data Logger
Daily data, memory depth > 5 years
Interface
Serial IR Interface
Controll wire PLA - AC ELWA
Wire line
0,5 - 1,5 mm²
Subject to change.
