04
4.0 Electrical Connection
l The electrical installation must be done by a qualified
electrician.
l MYSON KICKSPACE
®
comes equipped with a 2 metre
0.75mm
2
earthed power cable.
l The attached room thermostat also has a built-in main power
switch. For easy installation, use the provided wall adapter. The
adapter is used both for the room thermostat and the MYSON
KICKSPACE
®
unit.
l The room thermostat has a tolerance of max 10A. See Fig. 6
and connection diagram (Figs. 7a and 7b).
l If the power cable to the room thermostat doesn’t come
straight out of wall and into the thermostat housing, please
attach the provided pull relief on the inside of the room
thermostat.
WARNING: MYSON KICKSPACE
®
500, 600, 800, 80S & 80D - the unit must be earthed.
Do not energise the electrical supply until the remaining stages of the installation have been completed.
5.0 Controls
This unit is controlled by the switches on the front of the unit
(see Fig. 3).
Ensure the electricity supply is switched on.
Heating Mode
• Set the heating/fan only switch to heating
• Set fan speed control to position I
• The unit will now run on low fan speed.
The system water temperature on the return of the KICKSPACE
®
must be above 30°C for the fan to switch on*
*Eg. When the mean water temperature is greater than 30°C the
fan will switch on, then when the water temperature drops below
30°C the fan will switch off.
Performance will depend on the water temperature at the coil and
the flow though the coil.
The fan speed can be set to boost by switching the fan speed
switch to II.
A low speed setting is recommended for normal operation with
the higher speeds for boost heating when required.
Off Position
Set the fan speed selector switch to the off (O) position.
Fan Only Mode
If required, the KICKSPACE
®
can be used in summer for air
circulation without heat.
• Set the heating/fan only switch to fan only
• Adjust fan speed to required setting.
KICKSPACE
®
500, 600, 600-12V, 800, 80S & 80D
6.0 Troubleshooting
Fan not working in
heating mode
Possible Causes
Unit switched off
Room thermostat not calling for heat
Unit isolating valves shut
Water temperature of
KICKSPACE
®
below 30°C
Problem Remedy
Turn on
Turn up room thermostat
Open valves
Ensure boiler, pump and other central
heating equipment is working correctly,
if not contact your installer
Note: Operation of fan can be checked by
switching to fan only setting
Once installed this fan convector becomes an integral part of a
complete heating system that includes boiler, pump, other
emitters such as radiators and fan convectors, and a number of
heating controls, dependent on system complexity. An apparent
problem with this unit may be the result of system controls being
incorrectly set and can be solved easily without calling out your
installer. Before calling your installer, please carry out the checks
listed below.
KICKSPACE
®
500, 600, 600-12V, 800, 80S & 80D
INSTALLATION & OPERATING MANUAL
01.07.2018
EN
KICKSPACE
®
may have poor performance/cycle if a low water
temperature/flow rate is supplied, please refer to your installer as
this could be from the following:
• Unit incorrectly sized for heat loss of room
• Lack of flow to KICKSPACE
®
from heating system
• Pipe sizes/pump sized incorrectly
• System incorrectly balanced
If the fan convector is still faulty after checking the above, call your installer.
