NAD 114 - Technical Specifications; Phono Input Specifications; Line Level Input Specifications; Line Level Output Specifications

NA D
30
Phono Input
Input impedance (R and C) MM/MC
Input sensitivity ref.0.5V
Input overload at 20Hz/1kHz/20kHz
MM
MC
Signal/Noise ratio MM
(A-weighted with MC
cartridge connected)
THD (20Hz-20kHz) and IM dist.
RIAA response accuracy
Line Level Inputs
(CD,Video,Tuner,Tape 1, Tape 2, Aux)
Input impedance (R and C)
Input sensitivity ref.0.5V
Signal/Noise ratio, A-weighted ref. 1W
Frequency response, 20Hz-20kHz
Voltage gain
THD + SMPTE + IHF I.M.
Infrasonic filter
Line Level Outputs
Output impedance Pre out
Tape
Headphones
Maximum output level Pre out
Tape
Phones
Controls
Treble
Bass
Physical Specifications
Dimensions in mm (Width x Height x Depth)
Net Weight
Shipping Weight
47 k + 200 pF
1.5mV
20mV/200 mV/1700 mV
1.3mV/13 mV/110mV
78 dB ref. 0.5mV
76 dB ref. 0.5mV
<0.02%
±0.5dB 20Hz-20kHz
±0.5dB 50Hz-20kHz
–0.5 dB at 20Hz
20 k + 450 pF
80 mV
98dB
+0.2dB
16dB
<0.02%
–3dB at 10Hz
220
Source Z + 2k
120
>12V
>10V
>8V into 600
>250mV into 8
±7 dB at 10 kHz
±10 dB at 50 Hz
435 x 85 x 280
3.7kg
4.4kg
SPECIFICATION - NAD 114 PREAMPLIFIER
