NAD CI 580 - Advanced Connectivity and Control Ports; System Interrupt and Power Input

IDENTIFICATION OF CONTROLS
4 OPTICAL IN
• Connect to the corresponding optical digital output of sources such
as CD or BD/DVD players, digital cable box, digital tuners or any
compatible devices. The source will appear as an “Optical Input” in
the navigation drawer of the BluOS App.
DIGITAL PREAMPLIFIER OUTPUT (OPTICAL/COAXIAL 1-4)
• Connect any or all digital preamplier output ports to
corresponding optical or coaxial input ports of compatible
ampliers, receivers or processors.
• Audio output for each digital preamplier output is dependent
upon the current or selected source of the particular Player. This is
congurable via the BluOS App.
• Refer to the same sample table above showing selected sources for
particular Players and their corresponding preamplier or optical/
coaxial audio output.
5 LAN
• A wired Ethernet connection is required to setup the CI 580. Using
an Ethernet cable (not supplied), connect one end to CI 580’s LAN
port and the other end to the corresponding LAN port of your wired
Ethernet broadband router.
USB (Type A)
• Connect a USB mass storage device to the USB input. Typical USB
mass storage device compatible with CI 580 include portable ash
memory devices and external hard drives (FAT32 recommended).
• A notication will be shown in the BluOS App if a USB device is
inserted. Click on “USB” in the navigation drawer to browse and
playback content.
6 SERVICE
• This is not for consumer use. Only authorized service personnel can
access this SERVICE port.
7 +12V TRIGGER OUT
• The +12V TRIGGER OUT is used for controlling external equipment
equipped with a +12V trigger input.
• Connect this +12V TRIGGER OUT to the other equipment’s
corresponding +12V DC input jack using a mono cable with 3.5mm
male plug.
• This output will be 12V when the CI 580 is ON and 0V when it is
either OFF or in standby mode.
+12V TRIGGER IN
• With this input triggered by a 12V DC supply, the CI 580 can be
switched ON remotely from standby mode by compatible devices
such as ampliers, preampliers, receivers, etc. If the 12V DC supply
is cut o, CI 580 will return to standby mode.
• Connect this +12V Trigger input to the remote device’s
corresponding +12V DC output jack using a mono cable with
3.5mm male plug. The controlling device must be equipped with a
+12V trigger output to use this feature.
8 IR IN
• This input is connected to the output of an IR (infrared) repeater
(Xantech or similar) or the IR output of another component to allow
control of the CI 580 from a remote location.
• To program IR Remote commands into your CI 580 via IR IN, go
to the Settings menu of the BluOS App, select Player and then
IRremote. Simply select the function desired from the IRRemote
menu, point an IR remote control at the IR repeater and press the
button to perform that function. Once successful, a check-mark will
appear beside the programmed function.
9 SYSTEM INTERRUPT
• Doorbells or re alarms can be hooked-up via the supplied terminal
connector block. Refer to your doorbell or re alarm installation
procedure for proper connection with the CI 580.
• Once installed and connected, doorbell or re alarm activation will
immediately interrupt current source and buzzer or alarm will be
heard.
10 AC MAINS INPUT
• The CI 580 comes supplied with two separate AC mains power
cords. Select the AC mains power cord appropriate for your region.
An adaptor may be necessary in certain regions.
• Always disconnect the plug from the wall outlet rst, before
disconnecting the other end from CI 580’s AC mains power cord.
5
