Nady Systems Wireless Guitar Kit - Lightning Guitar Parts

HEADSTOCK
TUNING PEGS &
MACHINE HEADS
STRINGTREE
NECK &
FRETBOARD
NECK PICKUP
NUT
FRETS
LIGHTNING BOLT
FRET MARKERS
STRAP BUTTON
TRANSMITTER ON/OFF
SWITCH W/ LED INDICATOR
PLUG-IN OUTPUT
VIBRATO ARM,
aka "WHAMMY BAR"
VOLUME CONTROL
#5
#4
#3
#2
#1
5-WAY PICKUP
SELECTOR
SWITCH
#1 NECK PICKUP ONLY
#2 NECK & MIDDLE PICKUPS (HUM CANCELING)
#3 MIDDLE PICKUP ONLY
#4 MIDDLE & BRIDGE PICKUP (HUM CANCELING)
#5 BRIDGE PICKUP ONLY
PICKGUARD
STRAP BUTTON
MIDDLE PICKUP
BRIDGE PICKUP
BATTERY COMPARTMENT W/ MAGNETIC LATCH
DOOR FOR (2X) 9V ALKALINE BATTERIES
(BACK OF BODY)
BRIDGE
BODY
TONE (NECK PICKUP)
TONE (MIDDLE PICKUP)
Lightn ing Guitar Part s
T�
these terms for a better understanding of your instrument.
(4) (5)
