NAIM ACTIVE - Snaxo 2-4 Connection to Two NAP 250 Amplifiers; Wiring Diagram; Product Specifications; Snaxo Specifications

1 4
snaxo 2-4 connection to two NAP 250 power amplifiers
+ - - +
+ - - +
ch1, treble
ch1, bass
ch2, treble
ch2, bass
Specifications
snaxo
input impedance >10 kilohms
output impedance <50 ohms
crossover frequencies
2-4 credo, sbl 2.7kHz
3-6 nbl 250Hz, 2.8kHz
3-6 dbl 350Hz, 2.8kHz
filter slopes 18dB/octave
Case size (H x W x D) 76 x 205 x 300mm
ixo2
input impedance >10 kilohms
output impedance <50 ohms
crossover frequencies
credo, sbl 2.7kHz
filter slopes 18dB/octave
Case size (H x W x D) 58.4 x 430 x 300mm
4 pin DIN/XLR White
Interconnect Cables
