NAIM AV2 - Two-Channel System Setup

25
cable
direction
marker
4 to 4 pin DIN
reverse 5 to 5 pin DIN
Interconnect Cables
+- -+
+- -+ -+
link plug and cover fitted
av2
nap v175
nap 150
nac 112
to sub-woofer
surround
ch1, left
centre
surround
ch2, right
front
ch1, left
front
ch 2, right
12.4 nac 112/150 connected to av2 and nap v175
(two channel system with audio-visual added )
12.0 av2 connection diagrams
