Page 39
6-1 Adjustment Switches
The Adjustment switches are located inside the coin door.
1. Service Switch.
Press this switch to obtain game credits without incrementing the play meter, to
change the settings when in the Setting Mode and to select test numbers when in
the Test Mode.
2. Test Switch
Slide the test switch ON to enter test mode.
The Test Mode allows testing and the changing of game settings. (Refer to
sections 6-2 Setting Mode" page 40 and 6-3 Test Mode page 42)
3. Select Switch
This switch is used to select items when in the Setting Mode, and to operate
selected tests when in the Test Mode.
4. Volume Controls
These control the sound level of the speakers in the Target Cabinet and the Gun
Cabinet.
COIN COUNTER
TEST SERVICE
SELECT
2 Amp Q/B
(Coin Fuse)
VOLUME
VOLUME
