S08 MAINTENANCE
AIR INTAKE
WARNING !
Carry out these operations when the engine is stopped
and cold. Make sure that no dust or dirt enter the intake
manifold.
The reliability and the performances of the engine depend
among other things on the quantity and the temperature of
the global air intake design.
CHECK THE AIR FILTER BOX
1. Remove the holding clamps and remove the filter (in
blue on the picture).
2. Replace or clean the element.
3. If the air filter is crushed, flattened or punched, replace
it.
4. Install the new filter with new clamps. Do not overtight,
and not damage the inlet mouth.
Typical long life NANNI air filter
CLEANING THE AIR FILTER
Special tool
For best results, order the NANNI fi lter cleaning kit:
Number Description Illustration
970317077 Kit air filter cleaner
EN, ESP, SUOMI
OIL
SPRAY
CLEANER
SPRAY
970317078 Kit Air filter cleaner
FR, IT, DEU
Long life NANNI air filters require periodic cleaning.
Maintenance of these air filters is very simple. Please
follow the 4 steps below.
Cleaning: Spray liberally the
NANNI cleaner onto both sides of
the filter and let it soak for 10
minutes to loosen dirt. Do not
allow cleaner to dry up on the air
filter.
Rinsing: Wash the filter with cold
water at low pressure on the
outside to flush dirt out of the
filter. Continue rinsing until
removing all traces of cleaner. You
may need to repeat steps 1 and 2
several times.
Drying: After rinsing, shake off
any excess of water and let it
dry naturally. Do not oil the filter
before it is completely dry.
Oiling: Spray oil (Aerosol) evenly
on the crown of each pleat while
maintaining the nozzle at
approximately 8 cm from the filter.
Allow oil to penetrate into fabric
for around 20 minutes. Respray oil
wherever some white spots are
still visible on sides of the filter
until there is a uniform blue color
throughout.
