Napoleon S1 User Manual

W415-1226 / 06.27.13
21
EN
A
A
A
E
F
A
A A
A
K
A
A
A
A
A
A
D
D
A
A
A
A
I
J
A
B
K
K
B
BRICK
RETAINERS
G
H
(Fibre Baes)
W018-0078 X2
FIREBRICK
DIMENSIONS
PART #
FIREBRICK
DIMENSIONS
PART #
S1 S4 S9 S1 S4 S9
A
4 1/2” x 9”
(114mm x 229mm)
W090-0001
X12
W090-0001
X18
W090-0015
X20
G
2 1/4” x 9”
(57mm x 229mm)
W090-0018
X1
W090-0018
X1
W090-0018
X1
B
3” x 9” (Molded)
(6mm x 229mm)
W090-0002
X2
W090-000
X2
W090-0002
X2
H
1 3/4” x 4 3/4”
(64mm x 121mm)
W090-0216
X1
W090-0216
X1
W090-0216
X1
C
4 1/2” x 4 1/2”
(114mm x 144mm)
W090-0003
X2
N/A
W090-0003
X2
I
2 1/2” x 4 1/2”
(64mm x 114mm)
W090-0016
X1
W090-0016
X1
W090-0016
X1
D
3” x 9”
(76mm x 229mm)
W090-0166
X2
W090-0166
X2
W090-0166
X4
J
1 1/2” x 4 1/2”
(38mm x 114mm)
W090-0017
X1
W090-0017
X1
W090-0017
X1
E
4 1/2” x 9”(Notched)
(114mm x 229mm)
W090-0207
X1
W090-0207
X1
W090-0207
X1
K
4 1/2” x 8 1/2”
(114mm x 216mm)
W090-0210
X3
W090-0210
X3
W090-0210
X3
F
4 1/2” x 9”(Notched)
(114mm x 229mm)
W090-0208
X1
W090-0208
X1
W090-0208
X1
A
A
A
A
A
A
A
A
K
K
A
A
A
A
A
K
D
D
B
B
C
C
E
F
I
J
G
F
E
NOTE: BRICKS
E & F ARE
NOTCHED AT
REAR.
H
(Fibre Baes)
W018-0077 X2
BRICK
RETAINERS
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
K
A
K
K
A
B
B
D
D
I
J
G
A
A
C
C
D
D
F
E
(Fibre Baffles)
W018-0130 X2
H
BRICK
RETAINERS
S1, S4 & S9 (All Firebricks are 1 1/4” (32mm) Thick)
S4
S9
S1
