Chapter Three Operation and Maintenance
1. Parameters Setup
Table3-1 Energy storage system parameter setup table (600V system)
Parameter name
Unit
Grid
Off-grid
Floating Voltage per cell
V/cell
2.25
2.25
Equalization Voltage per cell
V/cell
2.30
2.30
Charging Current
A/cell
0.1C
10
0.2C
10
Discharge under-voltage protection
per cell
V
Please refer to table 3-2
Condition To Change Equalization
Charge To Float Charge
mA/Ah
＜5
＜5
Condition to Change Float Charge To
Equalization Charge
mA/Ah
＞50
＞50
Pack equalization voltage
V
690
690
Pack floating voltage
V
675
675
Pack charging current
A
0.1C10
0.2C10
Pack discharge under-voltage
protection
V
Please refer to table 3-2
Temperature Compensate Ratio With
Floating Voltage
mV/℃ /
cell
-3
-3
Temperature Compensate Ratio With
Equalization Voltage
mV/℃ /
cell
-5
-5
High Temperature Warning
℃
35
35
Short circuit protection current
A
Please refer to table 3-2
1. The voltage in above table is at 25℃. Please adjust the data according to table 3-3 at
other temperature.
2. Energy storage system can be off-grid power supply and grid power supply
according to real situation. The off-grid defined as tough power supply, to protect the
battery better, please set refer to above table or contact to manufacture.
3. Above are standard setup parameters in table 3-1. We suggest you to set up end
voltage (LVBD) based on different load current to make the battery life longer. Please
refer to table 3-2.
Table 3-2 Voltage setup parameter of LVBD and LVLD
Load current（A）
End voltage（V/cell）
LVBD（V/pack）
