INSTALLATION AND OPERATING
INSTRUCTIONS
NARVI SMOOTH 6,8kW
NARVI SMOOTH 9kW
NARVI SMOOTH 10,5kW
GB
Please read the manual carefully before you start installing and
using it and keep the manual for future reference. The products
are meant only to be used as a sauna heater and for heating
the sauna.
1. THE ELECTRIC HEATER SET INCLUDES:
1. Heater with control unit
2. Fastening plates and fastening screws
3. Temperature sensor
4. Control unit
5. Installation and operating instructions
2. BEFORE INSTALLATION:
Check on the following:
– Make sure the capacity of the heater (kW) corresponds to the size of the steam room (m
3
).
– Table 1 shows the heater types that correspond to various size saunas.
– If the steam room has any non-insulated brick, tile or glass surfaces, 1.5 m
3
of space must be added
to the size of the steam room for every square-meter of such surfaces. Based on the result, choose
the heater with the required capacity shown in table 1.
When choosing a heater, strictly adhere to the steam room space shown in table 1.
Table 1. Installation information for heaters
– The minimum height of the steam room and minimal safety clearances are shown in table 1.
– Make sure that the surface onto which the fastening plates are being screwed is sufciently strong.
Thin boarding is not sufcient. The surface can be reinforced with a supporting framework under
the boarding or reinforcing boards on top of the wall, which is connected to a wall framework.
– The oor under the sauna heater must be heat resistant. Hot pieces of the stones might drop on
the oor from the heater and cause re risk.
ONLY ONE ELECTRIC HEATER MAY BE INSTALLED IN EACH SAUNA ROOM.
Heater model Capacity Sauna room Minimal safety clearances to the heater Quantity
of stones
Connection *)
Volume Height on the
sides
at the
front
to the ceiling to the oor 5-10 cm 400 V
3N
Fuses
min max min A **) B **) C **) D **)
kW m
3
m
3
cm cm cm cm cm kg mm
2
A
Smooth 6,8 kW
6,8 5 8 190 10 10 70 3 100 5x1,5 3x10
Smooth 9 kW
9 8 14 190 10 10 70 3 100 5x2,5 3x16
Smooth 10,5 kW
10,5 10 18 210 10 10 90 3 100 5x2,5 3x16
**) See gure 1 *) Connected with rubber cable, type H07RN-F
or corresponding cable
TECHNICAL DATA:
- width 320 mm
- depth 320 mm
- height 1210 mm
- weight 15 kg
(without stones)
