National Instruments PXI-5691 User Manual

Hardware Front Panel Connectors and Indicators
ACCESS
ACTIVE
CH 0
IN
+30 dBm
MAX
IN
+30 dBm
MAX
CH 1
50 MHz - 8 GHz
OUT
+25 dBm
MAX
+20 dBm
MAX
Power
Reverse
OUT
+25 dBm
MAX
+20 dBm
MAX
Power
Reverse
50 Ω
50 Ω
50 Ω
50 Ω
Table 1. NI 5691 Front Panel Connectors
Connector Access Function
CH 0 IN Input CH 0 IN and CH 0 OUT each function as a fixed-gain amplifier.
These channels offer a low noise figure and a flat frequency response.
CH 0 IN and CH 0 OUT are AC-coupled.
CH 0 OUT Output
8 | ni.com | NI PXI-5691 Getting Started Guide
