Figure 2. PXIe-8881 Installed in a PXI Express Chassis
COOLING CLEARANCE REQUIRED. SEE MANUAL.COOLING CLEARANCE REQUIRED. SEE MANUAL.
1
3
2
1. PXI Express Chassis
2. PXI Express Controller
3. Injector/Ejector Rail
4 | ni.com | PXIe-8881 Getting Started Guide
