Figure 2. Installing the Brackets

5. Align the captive screws on the end brackets with the holes of the bottom brackets and

lightly tighten the screws, as shown in Figure 2.

6. Turn the VirtualBench face up and use your fingers and/or a #2 screwdriver to adjust the

angle of the VirtualBench as needed.

Figure 3. VirtualBench and the Desktop Mounting Kit

Note The desktop mounting kit will lift your VirtualBench off the surface of the

table by approximately 38 mm (1.5 in.). Total height will vary depending on the angle

that you set the feet. Allow for at least 23 mm (0.9 in.) on each side of VirtualBench

to accommodate for the end brackets.

1 Aligning the Two Bottom Brackets

2 Installing the Captive Screws of the End Brackets into the Holes of the Bottom Brackets
