Naturela NPBC-V6T-2 User Manual

Electronic pellet burner controller - NPBC-V6T-2
EXPLOTATION INSTRUCTION
The controller NPBC-V6T-2 is controlled from ”Control module” NRC-8. It has 3.5 '' IPS display
with capacitive touch sensor. It has virtual buttons or active places for control as well as by sliding
your finger in a certain direction (gesture).
Controller's main screen appears after turning the power supply on:
User Manual / ver. 1.2 http://www.naturela-bg.com/en/ page 11 of 41
Time
Boiler's water
temperature
External stop activated
(input OD)
Heater On
Information fields
Left side
Status bar with icons for the
outputs' current state and
the Internet connection
Main fan's speed
Fuel type used
at the moment
Date,
Burner's work phase (table 1)
or Registered errors (table 2)
Virtuals buttons for
main screen
Micro USB
Information fields
Right side
DHW Pump
CH Pump
