Naturela NPBC-V6T-2 User Manual

Electronic pellet burner controller - NPBC-V6T-2
INPUTS AND OUTPUTS OF NPBC-V 6T -2
Outputs Inputs
FM Main fan RT Room thermostat. To this input could
be connected a normally opened or
normally closed contact, with no
additional voltage.
FSG Fan for the flue gases PS Photo sensor
SF Screw for fuel RB Reverse burning sensor
SB Internal screw B Boiler temperature sensor
PH Heating installation pump WH Water heater temperature sensor
PWH Hot water heater pump PT pt100 high temperature sensor
IGN Hot water heater pump OD
Input for switch for Forced stop with
normally open or normally closed
contact or for vacuum switch
( pressure switch) with normally
closed contact.
FC Fan for cleaning or linear actuator
forward
LED
AUX Linear actuator backward (Option)
ACF Analogue fan output (Option)
DO NOT USE THE EXECUTIVE MODULE WITHOUT IT BEING INSTALLED IN A BURNER OR EXTERNAL BOX,
SO THAT NO EXPOSED CONDUCTIVE ELEMENTS ARE ACCESSIBLE. THERE IS A RISK OF ELECTRIC SHOCK WHEN
TOUCHING SOME ELEMENTS IN THE EXECUTIVE MODULE.
FOR BETTER OPERATION OF TOUCH DISPLAY, THE GROUND WIRE OF THE POWER SUPPLY MUST BE
CONNECTED TO THE PE INPUT OF THE POWER TERMINAL.
