NavePoint 6U - Parts Identification and Hardware; Rack Installation Hardware; Equipment Mounting Hardware; Required Tools

www.NavePoint.com
2
customerservice@navepoint.com
1. Parts Identification
A Wall Mounting Frame (2x)
B Horizontal Support Bar (2x)
C Equipment Mounting Frame (1x)
Rack Installation Hardware
D E F G
M5 Screws(8x) M4 Screws(8x) Bottom Metal Sleeves(2x) Top Sleeves(2x)
Equipment Mounting Hardware
H I J
M6 Mounting Screws (10x) M6 Cage Nuts(10x) 12-24 Mounting Screws(10x)
K L
M6 Metal Washers M6 Wall Mounting Screws
6U/9U/12U (x4) 6U/9U/12U (x4)
15U/18U (x6) 15U/18U (x6)
Tools Required: Phillips Screwdriver (not included)
