Connect to Lowrance Displays | 57
Optional Heading Sensor
Qnt Item Description Part No.
1
FC40 Fluxgate Compass
OR
RC42 Rate Compass.
Both the FC40 and RC42 have
5 m (16 ft) SimNet cables
attached.
Connect using the SimNet to
NMEA 2000 Adapter kit (000-
0127-45).
Alternatively use an
NMEA 0183 heading sensor and
connect via display unit power
cable.
22090245
22090237
Optional SimNet to NMEA 2000 Adapter kit (000-0127-45). Used to interface the above heading
sensors
Qnt. Item Description Part No.
1
SimNet to Micro C 24005729
N2K-T-RD T connector
Installed into the NMEA
2000 backbone
037-0491-01
1
SimNet cable joiner 44172260
To Next Page
