Nayax Onyx Installation Guide

Onyx Installation Guide Onyx_Installation_Guide_Ver.2.2.docx Page 11
Appendix 1- Insert SIM Card
The SIM Card is installed and included in the device. However, for any reason, if you need to insert a new
SIM then follow the steps below.
Step 1: Lift the SIM card slot by pulling the cradle towards you and insert the SIM card in the slot
Step 2: Lock SIM card in place by pushing the cradle down onto the main board. Slip the silver clutch
up to lock the card in place.
Note: Make sure that the SIM is inserted in the right direction as shown in the image above.

Nayax Onyx Specifications

General

Category	Card Reader
Contactless Payment	Yes
Operating Temperature	-10°C to 50°C
Payment Methods	Credit/Debit cards, Mobile wallets
Connectivity	Bluetooth, Wi-Fi, 4G
Security	PCI PTS 5.x
Card Reader Type	Chip, Contactless
Certifications	EMV
Battery Life	Up to 8 hours
Storage Temperature	-20°C to 70°C
Compliance	PCI DSS
