Nayax Onyx Installation Guide

Onyx Installation Guide Onyx_Installation_Guide_Ver.2.2.docx Page 9
Step 2. Connect Onyx cables
• Connect 40-pin connector plug to the device
• In case a coin mechanism is connected to the machine:
i. Disconnect the coin mechanism connector from the machine
ii. Connect coin mechanism connector to the Onyx cable
• Connect MDB/JVMA/Fuji connector to the machine’s connector
Step 3. Connect the external antenna
Step 4. Secure the device
Attach the bracket and the device with the help of 4 screws
Pro Tip: You may need a swiss spanner
wrench / Philips screwdriver for dismantling purposes.

Nayax Onyx Specifications

General

Category	Card Reader
Contactless Payment	Yes
Operating Temperature	-10°C to 50°C
Payment Methods	Credit/Debit cards, Mobile wallets
Connectivity	Bluetooth, Wi-Fi, 4G
Security	PCI PTS 5.x
Card Reader Type	Chip, Contactless
Certifications	EMV
Battery Life	Up to 8 hours
Storage Temperature	-20°C to 70°C
Compliance	PCI DSS
